Safety Features
All components are designed to keep safety as the first aspect of fan performance. Additional safety provisions are configured considering CE requirements.
Why You Choose
Austar HVLS FANS ?
- Suitable for workshop / building bigger than 2500 Sq. Ft & roof height more than 18ft.
- Uniform Air distribution
- Air Quality – Breeze Air [ A Gentle Wind ]
- Irritation less Longer hours exposure. ( workers can work comfortably for 10-12 hours )
- The human body feels 4 to 5 degree less. It is called wind chill effect “The air ‘feels’ colder than it is because of the chilling effect of the wind on the skin.”
- Reduced power consumption. ( 30% to 70% )
- Reduced Capital cost on Ventilation equipment
- Added aesthetics
Magical Advantages
Austar HVLS Fans have certain magical advantages against conventional Ceiling Fans / Wall Mounted Fans
| Features | Conventional Ceiling Fans / Wall Mounted Fans | HVLS Fans |
|---|---|---|
| Size | Maximum up to 36” (36 Inch) Diameter | 8 feet to 24 feet Diameter |
| Area Coverage | Need 100 No of Fans for 15000 Sq. feet Area | Need Only 1 Fan for 15000 Sq. feet Area |
| Power Consumption | 2.5 Watt / Sq. Feet Area | 0.1 Watt / Sq. Feet Area |
| Air Quality | Low Volume of Air at High Speed | High Volume of Air at Low Velocity |
| Comfort Feel | Gives Artificial feel | Gives Natural Breeze Air feel |
| Working Comfort | Person gets irritated after certain time | Person can stay / work for longer hours comfortably |
| Noise | Higher | Very Low |
| Maintenance | High | Low |
| Capital Cost | Low | High |
| Operating Cost | High | Low |
RETURN ON INVESTMENT (ROI)
There was a time before two Years only imported fans were available in Indian market.
Now Austar is catering India with Made in India HVLS Fans and reduced cost.
Let’s understand ROI with a case study.
| Details | Value |
|---|---|
| Area | 15000 Square Feet |
| Working Hours | 20 Hours |
| Working Days / Month | 25 Days |
| Total Working Hours / Year | 20 × 25 × 12 = 6000 Hours |
| No. of Conventional Fans | 30 Nos |
| No. of HVLS Fans | 1 No |
| Total Cost (Conventional Fans) | 8000 × 30 = ₹2,40,000 |
| Total Cost (HVLS Fan) | ₹2,40,000 |
| Extra Initial Cost | ₹0 |
| Power Consumption (Conventional) | 0.300 KWH × 30 = 9 KWH |
| Power Consumption (HVLS) | 1.5 KWH |
| Power Saving / Hour | 9 - 1.5 = 7.5 KW |
| Saving / Hour (₹7 per unit) | 7.5 × 7 = ₹52.5 |
| Yearly Working Hours | 12 × 25 × 12 = 3600 Hours |
| Total Saving per Year | ₹52.5 × 3600 = ₹1,89,000 |
KEY COMPONENT SPECIFICATIONS
Operated through KeyPad having easy and long life keys for Start / Stop, Reverse / Forward and Speed increase / decrease.Cable connection are through plug and play type for easy installation, maintenance and trouble free long lasting operation.Models are CE certified by third party agency ‘TUV Nord’
Gear Motor
Nord / SEW German make. IP 55 Protection, IE2 Efficiency, with Reinforced Bearing.
Blade Mounting Hub
Aluminium HE9 Grade. Die Casted Single Piece with Radiography tested.
Blades
Aluminium HE9 Grade. Having broadest blade section in market. Having Two Ribs for extra strength.
Paint
Driven by VFD of reputed make i.e Lenze / Danfoss / Crompton.
SAFETY PROVISIONS
Hanging Structure
Is made from IS 2062 M.S. tested raw material and welded by certified welders. All fasteners are selected with additional factory safety and all nuts are Nyloc Nuts. SS wire rope is wrapped twice among roof and fan hanging structure for extra safety.
Hub
Blade mounting hub is single piece die-cast LM6 aluminium grade material. All hubs are radiography tested for checking internal cracks if any.
Motor to Hub Couple
Motor and hub are coupled with fail-free couplings. Additional S clamps are provided to prevent fall out of hub in unlikely situations.
Blades
Blades are made from aluminium material with broad sections and two ribs for additional safety. Internal wire rope wrapping is provided to prevent fall out in case of blade breakage.
HVLS FANS AND THEIR USES AND BENEFITS
The High-volume Low-speed Fan is shortly known as an HVLS FANS. It is a Mechanical Fan that distributes a large amount of air at low rotational speed and its SIze is at least feet (2.1 m) or greater, hence the name high volume low speed. The fan smoothly mixes the layers of air to maintain a comfortable temperature without raising the heat. It is an effective cooling or heating solution for large spaces. This Fan is generally mounted on the ceiling although some are pole mounted.
Cooling a large premise is a very complicated process. Large ceiling fans are designed to move a high volume of air at low speed creating a blowing breeze environment on any premise. They are normally installed in Airports, Godowns, warehouses, shopping malls, Animal sheds, Hospitals, Schools, Dairy farms, Horse Stables, hangars, and more. The large ceiling fans are versatile, environmentally friendly, and cost-effective fans. They are very much suitable for industrial and commercial spaces. The Austar HVLS Fans are suitable for workshop or building that is bigger than 2500 Sq. Ft and the roof height more than 18ft. These fans also contribute to increasing the productivity of the workers.
HOW DO THEY WORK?
Usually, there are air conditioners installed in the large premises to keep the place cool. The air conditioner keeps the place cool, while the HVLS fan keeps the people cool. The HVLS fans more temperature consistent. The fan does not directly heat or cool the air, but it can make the place more comfortable and the environment more pleasant.
The fan distributes and increases the airflow in the room constantly. The fan pushes air down from the ceiling and pulls the air up from the floor and thus distributing air all around the room and giving a natural breeze-like feeling.
Normally the cool air remains at the bottom on floor level and hot air remain at the top on ceiling level. In this way, air separates into layers and this Is called stratification. The industrial ceiling fan mixes the layers or air together and evaporative cooling happens. Ine ran blows a high volume of air toward the floor and then the air migrates outwards until it reaches a sidewall. As soon as the air reaches a side wall or any vertical surface, it turns upward and flows back towards the ceiling. In this way, air circulates in the room and the increased air circulation effectively removes hot humid air and replaces it with cool air.
How Do They Work
The ceiling fan accelerates the evaporation of moisture of the body and creates a cooling effect. The fan increases the evaporative heat loss from the body and helps keep the skin cool. The evaporative effect also works to eliminate humidity from the air. The fan minimizes the dampness in the air and keeps the air dry, thus making the place more comfortable. The cool breeze flows throughout the premises and it gives a pleasant feeling to the occupants.
The HVLS fans are able to move in reverse. Usually, a fan moves counterclockwise, but for a large ceiling fan, you can change the system to move in the reverse direction during the winter season.
The hot air remains at the top and the cool air remains at the bottom. In wintertime, the occupants are left with cold air at the bottom and thus the temperature becomes uncomfortable for them. An HVLS fan by moving in the reverse direction mixes the hot air with the cool air and maintains a comfortable temperature without raising the heat.
USEFUL IN VARIOUS INDUSTRIES
01
Large Space Requirement
The HVLS fans are normally needed in large places where people are working, seating, or standing for some activity. In large places where air movement is not available, the occupants feel suffocated, and here the need for this fan arises. These fans are originally designed for installation in large spaces such as factories, workshops, barns, hangars, animal sheds, and more.
02
Industrial Establishments
The HVLS fans are very useful in industrial establishments and commercial establishments. In an Industrial establishment generally, HVAC systems are installed. The HVAC system cools the room, but it cannot give the feel of a cool breeze flowing around the room. Here the HVLS fan works to distribute the air uniformly on the premises. The people working there would feel a pleasant breeze on their skin and they would enjoy staying and working there. This can increase the productivity and efficiency of the workers.
03
Commercial Establishments
industrial ceiling fans are very useful at the Commercial establishment. Several people come to visit in commercial establishments. There is air conditioning on the premises, but it does not give the feeling of a cool breeze. The customers might feel uneasy, and they would not stay longer. The industrial ceiling fan circulates the cool air and creates a flowing breeze environment; thus, customers would feel good and stay long and might purchase more as well.
How HVLS Fans Got Appreciation in Countries Like India
Before HVLS fans got introduced in INDIA, most of the big industrial and commercial buildings were using either HVAC systems or conventional wall-mounted Air Circulating Fans.
Being Capital and Operation cost of the HVAC system at a higher nod, most of the users tend to use wall-mounted Air Circulator Fans. Wall-mounted Air Circulators also have their own challenges like High Noise level, Limited area coverage, Frequent Maintenance, Limited working life, etc.
Once HVLS fans got introduced, users got solutions to both of these two options HVAC and Wall Mounted Air Circulator Fans. Capital cost and Operation cost of HVLS Fan found very less than HVAC systems and Performance and comfort very high than Air Circulators.
In some the applications like Airports, HVLS Fans are used to reduce HVAC operation costs also.
